In the given figure switches ${S}_{1}$ and ${S}_{2}$ are in open condition. The resistance across $ab$ when the switches ${S}_{1}$ and ${S}_{2}$ are closed is ________$\Omega .$

Your answerCheck answer

Show answer and solution▾

Answer: 10

when switch ${S}_{1}$ and ${S}_{2}$ are closed

$\left(\dfrac{12\times 6}{12+6}\right)+2+\left(\dfrac{6\times 12}{6+12}\right)$
$\dfrac{72}{18}+2+\dfrac{72}{18}=4+2+4=10\Omega$
