Question 171 of 209
Identify the logic operation performed by the given circuit
Show answer and solution
Answer: (A) AND gate
According to the circuit,
Output
Thus, the given circuit is a AND gate.
Semiconductors
JEE Main level, single correct, medium
Identify the logic operation performed by the given circuit
According to the circuit,
Output
Thus, the given circuit is a AND gate.
